Electrical Data |
- |
Type: Colinear |
- |
Frequency range @ SWR ≤ 1.5:
SPO-380-5: 380-430 MHz
SPO-420-5: 420-470 MHz |
- |
Impedance: 50Ω |
- |
Radiation (H-plane): 360° omnidirectional |
- |
Radiation (E-plane): beamwidth @ -3 dB = 40° |
- |
Radiation angle: 0° |
- |
Polarization: linear vertical |
- |
Gain: 3 dBd - 5.15 dBi |
- |
Max. power (CW) @ 30°C: 75 Watts |
- |
Grounding protection: All metal part are DC-grounded, the inner conductor shows a DC-short |
- |
Connector: N-female with rubber protection cap |
|
|
Mechanical Data |
- |
Materials: White fiberglass radome Ø 28.6mm, anodized 6063-t5 aluminium, brass, stainless steel, copper, EPDM rubber |
- |
Wind load / resistance: 53 N @ 150 Km/h / 180 Km/h |
- |
Wind surface: 0.044 m² |
- |
Height (approx.): 1380 mm |
- |
Weight (approx.): 1200 gr |
- |
Operating temperature: -40°C to +80°C |
- |
Mounting mast: Ø 35-54 mm |
